Product Details：
It can realize secondary cooling and automatic de-flashing of products.
20-30L five-layer automated production line product manual
Double or single frame, single or double die
Die center distance: double head 320mm
Single to three layers with transparent lines
Daily production (24 hours) up to 50 seconds
Can produce 20-30L plastic hollow products
Fully automated, high volume production of blow molding products
This model produces four 10L barrels for a cycle of about 40-50 seconds, or two 30L barrel high speed blow
molding machines for one cycle of about 50-60 seconds.
Technical Parameters:
Screw diameter: Φ90mm
Screw ratio (length, diameter): 30:1
Screw speed (50HZ): 10-75 r/min
Extrusion amount (PE): 180kg/h
Barrel heating section: 6
Molding stroke: 640mm
Mode locking stroke: 380-750mm
Clamping force (160Bar): 30T
Dry cycle: 6.9S
Rubber thickness control: 100-300dpi
Cooling water consumption: 0.6 M3/min (0.3Mpa, 180C)
Compressed air consumption: 4.0 M3/min (0.8Mpa)
Mechanical net amount (approximately): 22T
Power consumption parameter
Frequency conversion motor: 55KW
Screw heating section (PE): 27KW
Hydraulically driven servo motor: 37+4KW
Die heating section: 16KW
Maximum power consumption of machinery: 139KW
